GHSL1742/1842/ FULL RISE SCISSOR LIFT

◆Super low profile and perfect for ground mounted;

◆Suitable for any positioning turn table;

◆Equipped with safety lock, makes the run way more stable ,and more safety operating;

◆Equipped with second lifting jack,which equipped with telescopic sliding beam and bracket.



·

Technical Specification

Rating capacity 3500/4000kg
Runway length 4200/4500mm
Runway Width 635/635mm
Max. Lifting height 1700/1700mm
Min. height 190/190mm
Lifting time 60s
Ack capacity 2500kg
Central jack raised height 450mm
Motor power 2.2kw
Power supply 380V/415V 3phase
Air supply 6~8Kg/cm2
Packing size 4600/4900*650*700
Weight 2167/2277kg
9 units can be loaded into one 20”container
  Details
  Packing size and line drawings
